Hydraulic Press

We manufacture hydraulic presses that combine a robust body structure with a stylish appearance and incorporate future-proof technologies. We elevate your production to Industry 4.0 levels with historical production statistics, robot integration, driver integration, mold recording, and server connectivity. We manufacture machines that prioritize operator safety with features such as fully enclosed cabins, light barriers, and two-hand buttons. Automatic lubrication, maintenance reminders, and hydraulic coolers ensure long-term durability. Thanks to the universal design of our presses, we've designed them for use in a wide variety of production areas.

The PLC monitors pressure instantly and positions it using a ruler. The press's lift-off and lift-off points, as well as the force it will apply, can be easily adjusted on the screen. All parameters are recorded separately for each mold, and settings can be automatically retrieved during mold changes without wasting time.

Our presses feature a dual-action lower ejector mechanism. This allows for automatic removal of products from the mold in production areas such as sheet metal parts production and jewelry. With the robot and drive connection we offer as standard, you can easily adapt your custom-designed feed units to our press.

The Hydraulic Presses we produce serve a wide variety of applications. Some examples of the areas where our hydraulic presses are used:

Form Press, Drawing Press, Deep Drawing Press, Trial Press, Practice Press, Cutting Press, Jeweler's Press, Calibration Press, Transfer Press, Attaching Press, Assembly Press, Gold Press

Hydraulic Press

MODEL	HP403	HP406	HP410	HP610	HP615	HP620	HP915	HP920	HP925
Table Size	400 X 400			600 X 500			900 X 600
Compression Force (250 Bar)	40 Tons	80 Tons	125 Tons	125 Tons	200 Tons	250 Tons	200 Tons	250 Tons	300 Tons
Compression Force (200 Bar)	30 Tons	60 Tons	100 Tons	100 Tons	150 Tons	200 Tons	150 Tons	200 Tons	250 Tons
Motor Power (kW)	3	5,5	7,5	7,5	11	15	11	15	18,5
Number of Cylinders	1	1	1	1	2	2	2	2	3
Cylinder Diameter	150	200	250	250	230	250	230	250	230
Stroke	250 mm			300 mm			350 mm
Maximum Clearance	300 mm.			350 mm.			400 mm.
Minimum Clearance	50 mm.			50 mm.			50 mm.
Press Speed	10 mm/sec.
Ruler	It can be easily adjusted to work between the desired points by adjusting the starting and ending points on the screen with the ruler.
Safety Barrier	Available.
Line Integration	Electrical connections for the driver, power supply unit, and robot are standard. It can be easily connected and used. It also supports various connection protocols.
Control Unit	All functions and measurements are controlled by PLC.
Memory	1000 molds can be saved with all their parameters.
Control Panel	7" Touch panel
Hydraulic Oil Cooling	Temperature controlled, separate pump prevents oil temperature from increasing.
Automatic Lubrication	The machine automatically lubricates its columns, eliminating the need for daily maintenance.
Middle Pusher	With the hydraulic middle pusher, you can move the mold core separately and remove the product from the mold.
Shift Tracking	It records the production amount of 3 monthly shifts and stores it in its non-erasable memory.
Online Working and Remote Control	It transfers data instantly to the server computer. The machine can be controlled remotely.
Energy Consumption Tracking	Tracks energy consumption for 3-month shifts. You can easily see the unit energy consumption per product and the machine's energy consumption.
